FUNCTION TEST
SERVICE
REPORT
JOB NO: 20110118
1 | P a g e
VESSEL:
LOC:CHINA (HRRD)
DATE:
MAKE: MITSUBISHI
EQUIPMENT:STEER GEAR (NO.1 & NO.2)

MODEL: 06V-FH2B-MK

DEFECTS REPORTED / REASON FOR CALL: TO INSPECTION AND SERVICE.
ITEM
DESCRIPTION
REMARKS
1
FUNCTION TEST:-
Port and stbd steer gear pump function tested found both pumps shaft seal area
leaking. Discussed with chief engineer both pumps shaft seals to renew.
DISMANTLING
Both pumps electric motors and
2
associated pipe connects, links
removed.
Coupling extracted.
HYDRAULICS AND AUTOMATIONS SPECIALISTs - Sales & Service Centre
HANLA, HAEAN, PUSNES, KRACHT, KAWASAKI, KAYABA, JANNEY, DONGNAM
25 years over 7000 track records. www.joblist.raycontrol.com
RENEW SHAFT SEALS
SERVICE
REPORT
RayControl Pte Ltd
7 TOH GUAN ROAD EAST #05-07 ALPHA IND BLDG SINGAPORE 608599
TEL: +65 65630544 FAX: +65 65600941 email:sales@raycontrol.com
JOB NO:2011
Company Reg No : 198602637N
Affiliated : E-Trust Automation Pte Ltd
2 | P a g e
3
RENEW SHAFT SEALS
Existing shaft seal found brittle and worned. no good condition.
New shaft seals renewed for both pumps.
4
PRESSURE LINE FILTERS
Dismantled and found pressure line filters in almost choke condition.
Renewed both pumps pressure line filters.
HYDRAULICS AND AUTOMATIONS SPECIALISTs - Sales & Service Centre
HANLA, HAEAN, PUSNES, KRACHT, KAWASAKI, KAYABA, JANNEY, DONGNAM
25 years over 7000 track records. www.joblist.raycontrol.com
LINE UP STEER GEAR FOR NORMAL OPERATION
SERVICE
REPORT
RayControl Pte Ltd
7 TOH GUAN ROAD EAST #05-07 ALPHA IND BLDG SINGAPORE 608599
TEL: +65 65630544 FAX: +65 65600941 email:sales@raycontrol.com
JOB NO:2011
Company Reg No : 198602637N
Affiliated : E-Trust Automation Pte Ltd
3 | P a g e
5
Reinstalled coupling, el motors, align, refit connections etc.
LINE UP STEER GEAR FOR NORMAL OPERATION
Carried out FULL STYLE FUNCTION TESTs
On NFU, Hand Wheel, Emergency and
Swing Test satisfactory in presence of Chief Engineer.
REPORT BY
HASAN
Senior Service Engineer
