PUSNES Control Station to repair
SERVICE REPORT
Page 1 of 2
MASTER and OWNER of
JOBNO
20110128
PO NO
VESSEL NAME
AUTHORISE BY
LOCATION
SG
DATE
28 JAN 2011
EQUIPMENT
Anchor Winch
MAKE/MODEL
PUSNES HYDRANOR
TO DO

PUSNES Control Station to repair

WORK CARRIED OUT/DESCRIPTION
REMARKS
Collected control station from other contractor on
instruction of attending superintendent.
Found control station in dismantle condition.
In 02 halves and many loose internal parts.
Informed superintendent unable to carry out
repair and there are too many missing parts.
On insistence of super, collected a second batch of
loose parts from other contractor.
On inspection found still unable to repair as
sensitive internal parts like spools, springs etc are
still missing.
On insistence of super, agreed to help out
SERVICE REPORT
7 TOH GUAN ROAD EAST #0507 SINGAPORE 608599
Tel: +65 65630544 Fax: +65 65600941 sales@raycontrol.com
Company Reg No : 198602637N GST Reg No: M200745370
Page 2 of 2
On insistence of super, agreed to help out
Complete lay out of control block parts. Piece
together all parts that’s useable and sort out those
missing.
Have to backtrack and study tediously every
control block channels and plan out internal
bypasses and modification.
Each and every one bypasses or modifications
carried out with each testing and finally
 found success.
Renewed 01 main directional valve and
counterbalance.
Tested 250 bar satisfactory.
Parts Supplied :-
01 No Main Directional Valve C7J30
01 No Counterbalance Valve
01 Set Dowty Seal Ring
01 Set Washer
Attended by
Acceptance By
Service Engineer
Name/Rank
Name
Sign and Stanp
